　　在油煙彌漫的廚房、充滿粉塵的車間或是需要空氣凈化的實驗室，排煙系統如同“空間肺葉”，默默吞吐著空氣的質量。面對直排式與循環式兩種技術路線，選型決策絕非“非此即彼”的簡單選擇題，而是需要結合空間特性、使用場景與核心需求展開的多維度權衡。本文將為您拆解兩種系統的技術基因，構建一套立體的選型邏輯。

　　In kitchens filled with oil fumes, workshops filled with dust, or laboratories that require air purification, the exhaust system is like a "spatial lung" silently inhaling and exhaling the quality of the air. Faced with the two technological routes of direct and cyclic, selection decision-making is not a simple multiple-choice question of "either or", but requires multidimensional trade-offs based on spatial characteristics, usage scenarios, and core requirements. This article will break down the technical genes of two systems and construct a three-dimensional selection logic for you.

　　一、技術基因解碼：直排式與循環式的底層差異

　　1、 Technical gene decoding: the underlying differences between inline and cyclic approaches

　　直排式系統如同“空氣單行道”，通過風機將污染空氣直接排向室外。其技術核心在于大風量與高靜壓，如同給空間裝上“排氣閥”，在油煙濃度高的商用廚房、焊接車間等場景占據主導。但這種“粗暴”的排氣方式也暗藏隱患：冬季熱量流失、夏季冷氣外泄，相當于在門窗縫隙外又開了一道“隱形氣窗”。

　　The direct exhaust system is like an "air one-way street", where polluted air is directly discharged outdoors through fans. The core of its technology lies in high air volume and high static pressure, similar to installing "exhaust valves" in spaces, which dominate in commercial kitchens, welding workshops, and other scenarios with high oil fume concentration. But this "rough" exhaust method also carries hidden dangers: heat loss in winter and cold air leakage in summer, which is equivalent to opening another "invisible air window" outside the gaps between doors and windows.

　　循環式系統則更像“空氣凈化器+新風系統”的合體，通過多層濾網攔截污染物后，將潔凈空氣重新送回室內。其技術壁壘在于濾網壽命與熱回收效率，高端機型甚至能集成紫外線殺菌、等離子除味等功能。但循環式系統并非萬能，在重油煙場景下，濾網飽和速度可能快過廚師顛勺頻率。

　　A circulating system is more like a combination of an air purifier and a fresh air system, intercepting pollutants through multiple layers of filters and sending clean air back indoors. The technical barrier lies in the lifespan of the filter and the efficiency of heat recovery. High end models can even integrate functions such as ultraviolet sterilization and plasma deodorization. But a cyclic system is not omnipotent. In heavy oil fume scenarios, the saturation speed of the filter may be faster than the frequency of the chef shaking the spoon.

　　二、場景化選型：從廚房到實驗室的呼吸方案

　　2、 Scenario based selection: Breathing plan from kitchen to laboratory

　　場景1：家用廚房

　　Scenario 1: Home Kitchen

　　直排式適用場景：開放式廚房、飲食清淡的家庭。直排式能快速清除爆炒產生的油煙，避免氣味擴散。但需注意：若廚房無獨立外排通道，直排式可能導致油煙倒灌。

　　Direct layout is suitable for open kitchens and households with light meals. Direct exhaust can quickly remove the oil fumes generated during stir frying, avoiding the spread of odors. However, it should be noted that if the kitchen does not have an independent exhaust channel, a straight exhaust system may cause oil fume backflow.

　　循環式適用場景：封閉式廚房、有嬰幼兒的家庭。循環式避免了對室內溫濕度的影響，但需定期更換濾網，且對煎炸等重油煙場景處理能力有限。

　　Circular application scenarios: enclosed kitchens, households with infants and young children. The cyclic method avoids the impact on indoor temperature and humidity, but requires regular replacement of the filter and has limited ability to handle heavy oil fume scenarios such as frying.

　　場景2：商用廚房

　　Scenario 2: Commercial Kitchen

　　直排式必選理由：在日均工作12小時以上的餐廳后廚，直排式是唯一能扛住高負荷的選擇。某連鎖餐飲實測數據顯示，直排式系統在5年生命周期內的總擁有成本（TCO）反而低于循環式，因濾網更換與維護成本被大風量帶來的效率優勢抵消。

　　Reason for choosing straight row style: In restaurants with a daily working time of more than 12 hours, straight row style is the only option that can withstand high loads. According to actual test data from a certain chain restaurant, the total cost of ownership (TCO) of a direct exhaust system over a 5-year lifecycle is actually lower than that of a circulating system, as the cost of filter replacement and maintenance is offset by the efficiency advantage brought by high air volume.

　　循環式突破點：若廚房位于建筑中庭或無法開鑿排煙管道，循環式配合靜電吸附濾網，可實現95%以上的油煙凈化率，但需配備大容量集油盒與自動清洗功能。

　　Breakthrough point of circular type: If the kitchen is located in the atrium of the building or cannot excavate smoke exhaust pipes, the circular type combined with electrostatic adsorption filter can achieve a smoke purification rate of over 95%, but it needs to be equipped with a large capacity oil collection box and automatic cleaning function.

　　場景3：工業車間

　　Scenario 3: Industrial Workshop

　　直排式主場：在金屬加工、石材切割等粉塵濃度超標的場景，直排式配合沉降室使用，能快速降低爆炸風險。但需加裝消音器，否則風機噪音可能超過90分貝。

　　Direct discharge main field: In scenarios where dust concentration exceeds the standard, such as metal processing and stone cutting, direct discharge combined with a settling chamber can quickly reduce the risk of explosion. But a silencer needs to be installed, otherwise the fan noise may exceed 90 decibels.

　　循環式創新應用：在電子無塵車間，循環式系統通過HEPA濾網與活性炭吸附，能將0.3μm顆粒物過濾效率提升至99.97%，但需嚴格控溫濕度，避免靜電吸附濾網產生臭氧。

　　Circular innovation application: In the electronic dust-free workshop, the circular system uses HEPA filters and activated carbon adsorption to increase the filtration efficiency of 0.3 μ m particles to 99.97%. However, strict temperature and humidity control are required to avoid electrostatic adsorption of ozone by the filter.

　　場景4：實驗室

　　Scenario 4: Laboratory

　　直排式底線：涉及揮發性化學品的實驗室，直排式是安全紅線。但需設計負壓環境，防止有毒氣體外泄。

　　Straight line bottom line: For laboratories involving volatile chemicals, straight line is the safety red line. But a negative pressure environment needs to be designed to prevent the leakage of toxic gases.

　　循環式進化方向：在生物安全實驗室，循環式系統集成高效過濾器（HEPA）與氣溶膠監測模塊，實現空氣的“閉環凈化”，但初期投入成本是直排式的3倍以上。

　　Circular evolution direction: In biosafety laboratories, circular systems integrate high-efficiency particulate air (HEPA) filters and aerosol monitoring modules to achieve "closed-loop purification" of air, but the initial investment cost is more than three times that of direct discharge systems.

　　三、能效與成本：被忽視的隱形戰場

　　3、 Energy Efficiency and Cost: The Neglected Hidden Battlefield

　　直排式系統的能效陷阱在于“熱量偷竊”：冬季每排出1m?空氣，可能帶走室內30W的熱量。以100㎡餐廳為例，冬季每月因排煙導致的供暖成本增加可能超千元。而配備熱回收模塊的循環式系統，能將70%的排風熱量回收，但熱交換芯體需每3年更換一次。

　　The energy efficiency trap of a direct exhaust system lies in "heat theft": for every 1m ? of air discharged in winter, it may take away 30W of indoor heat. Taking a 100 square meter restaurant as an example, the monthly increase in heating costs due to smoke exhaust during winter may exceed a thousand yuan. The circulating system equipped with a heat recovery module can recover 70% of the exhaust heat, but the heat exchange core needs to be replaced every 3 years.

　　維護成本方面，直排式系統看似“皮實耐用”，但若未定期清洗風管，油垢堆積可能導致火災風險。某酒店火災調查顯示，排煙管道油垢厚度達5mm時，自燃溫度可低至230℃。而循環式系統的濾網更換成本，可能占到總維護成本的60%以上。

　　In terms of maintenance costs, the direct exhaust system may seem "sturdy and durable", but if the air ducts are not cleaned regularly, the accumulation of oil and dirt may lead to fire risks. A fire investigation in a certain hotel showed that when the thickness of oil stains in the exhaust pipe reaches 5mm, the self ignition temperature can be as low as 230 ℃. The cost of replacing the filter screen in a cyclic system may account for over 60% of the total maintenance cost.

　　四、選型決策樹：三步定位最優解

　　4、 Selection decision tree: three-step positioning of optimal solution

　　第一步：判空氣質量

　　Step 1: Assessing Air Quality

　　若污染物為顆粒物（如粉塵、油煙），優先選直排式；

　　If the pollutant is particulate matter (such as dust, oil fume), direct discharge is preferred;

　　若為氣態污染物（如VOCs、異味），循環式更優。

　　If it is a gaseous pollutant (such as VOCs, odors), the cyclic type is better.

　　第二步：算空間賬

　　Step 2: Calculate the space account

　　開放式空間選直排式，避免污染空氣擴散；

　　Choose an open space with straight rows to avoid the spread of polluted air;

　　密閉空間選循環式，減少溫濕度波動。

　　Choose a circular design for enclosed spaces to reduce temperature and humidity fluctuations.

　　第三步：核成本表

　　Step 3: Verify the Cost Table

　　初期投入：直排式≈循環式×0.6；

　　Initial investment: Direct flow ≈ Circular flow × 0.6;

　　5年TCO：直排式可能反超循環式，因濾網更換與熱回收模塊損耗。

　　5-year TCO: Direct discharge type may have reverse circulation type due to filter replacement and heat recovery module loss.

　　在排煙系統的選型戰場上，沒有絕對王者，只有場景適配。直排式如同“空間清道夫”，用簡單粗暴的方式守護空氣質量；循環式則像“空氣管家”，在凈化與節能間尋找平衡。

　　In the battlefield of smoke exhaust system selection, there is no absolute king, only scene adaptation. The straight row style is like a "space cleaner", guarding air quality in a simple and rough way; Circulating is like an "air steward", seeking a balance between purification and energy conservation.
